Planetary Laboratory Ball Mill Machine Grinding 0.37KW 0.1um Granularity

  • Planetary Laboratory Ball Mill Machine Grinding 0.37KW 0.1um Granularity
  • Planetary Laboratory Ball Mill Machine Grinding 0.37KW 0.1um Granularity
  • Planetary Laboratory Ball Mill Machine Grinding 0.37KW 0.1um Granularity
Place of Origin China
Brand Name ZHIK
Certification CE IOS
Model Number ZK-XGB04
Minimum Order Quantity 1 Set
Price 3000
Packaging Details Wooden packing
Delivery Time 20
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 15set/month
Product Details
Power 0.37KW Output Granularity Up To 0.1um
High Light

Planetary Laboratory Ball Mill Machine

,

0.37KW Laboratory Ball Mill Machine

,

0.1um ball mill grinding machine
Leave a Message
Product Description
Lab Planetary Bench-top battery Ball Mill Grinding Machine Grinder w 4 Alumina Jars or Agate Jars or ZrO Jars & Quick Cl
Product Description

The planetary ball mill can use dry and wet methods to grind or mix solid particles, suspensions and pastes with different particle sizes and different materials. If a vacuum ball mill can be used, the sample can be ground and mixed in a vacuum or inert gas. This series of ball mills are widely used in geology, metallurgy, soil, building materials, chemicals, light industry, medicine, electronics, ceramics, batteries, environmental protection and other fields



Planetary Laboratory Ball Mill Machine Grinding 0.37KW 0.1um Granularity 0



Technical Parameter


power
0.37KW
power supply
220V 50HZ
Display method
LED display, and can display the speed of ball mill
transfer method
gear drive
Way of working
Two or four ball mill tanks working simultaneously
Loading capacity
Two-thirds of the ball mill tank volume
Abrasive method
Can be dry or wet Stainless steel vacuum cans can be ball milled under aerated or vacuum conditions. With a stainless steel vacuum
sleeve, other common cans can be sheathed, so that the materials are in
agate, zirconia, polytetrafluoroethylene, etc., under aerated or vacuum ball milling.
Feed size
Soil material ≤10mm, other materials ≤3mm
Output granularity
Up to 0.1um
Speed ​​ratio
(Roller speed: ball mill tank speed) 1: 2
Rotation speed of ball mill tank
00 ～ 600 rpm
Disk speed
00 ～ 300 rpm
control method
Variable frequency stepless speed regulation and program control
intelligent control
With timing, automatic shutdown function. Able to set automatic forward and reverse rotation, set intermittent rotation Open lid
and power off
Maximum continuous working time
(full load) 72 hours
Models that can be equipped with ordinary ball mill tanks
(Can fit 4 such jars) 50ML 100ML
Models that can be equipped with stainless steel vacuum ball mill tanks (can fit 4 such tanks)
50ML
Models that can be equipped with stainless steel vacuum ball mill sleeves (can fit 4 such jars)
50ML
